Heavy Duty Linear Block SGL

SGL 15/20/25/30/35/45/55/65

Hiwin HGl interchangeable linear block

Block types: extended square
Material：Standard/Full Metal
Accuracy grades: C, H, P
Sizes: 15, 20, 25, 30, 35, 45, 55, 65
Block mounting types: top mounting / bottom mounting / top or bottom mounting
Dust protection options:
Oil scraper + end seal + metal scraper
Double oil scraper + end seal + metal scraper
Double oil scraper + end seal

Why DTX-LG linear guide carriage?

01. High-Strength Materials

DTX-LG HGL compatible linear block is manufactured from premium steel and undergoes advanced heat treatment, achieving a surface hardness of 59–62 HRC. This ensures excellent wear resistance, higher load capacity, and extended service life even under heavy-duty conditions.

Each linear guideway carriage is equipped with high-quality steel balls hardened to 61–66 HRC. The superior hardness provides outstanding rolling performance, enhances load distribution, and guarantees smooth, precise linear motion with minimal friction.

02. Design in Taiwan, made in china

Each linear guideway block is manufactured in-house with CNC drilling and grinding to ensure accuracy and consistency. With 16 production lines and an annual output of 3,600,000 pieces, DTX-LG guarantees strict quality control, large-scale supply, and reliable delivery worldwide.

Become Distributor →

03. Advanced Self-Lubrication System

A built-in lubrication mechanism is integrated into the end cap, consisting of an oil storage unit and an oil release unit. The oil guide element inside not only absorbs and stores oil but also gradually releases it to the raceway through its special structure. This design ensures continuous lubrication, significantly reduces maintenance requirements, and keeps the block running reliably over long periods. Fully interchangeable with linear guideway block hiwin.

04. Ensuring Cleanliness and Reliability Before Assembly

Each heavy-duty linear guide block undergoes a thorough ultrasonic cleaning process to remove machining residues, fine metal particles, and surface impurities. This is followed by hot air drying to eliminate moisture and prevent corrosion. Only after these cleaning and drying steps are completed does the block proceed to the assembly stage, ensuring that every guideways block maintains a clean, contaminant-free surface for smooth motion and long-term reliability.

05. A Full-Cycle ISO Quality Management System

DTX-LG has obtained multiple ISO certifications and fully implements standardized ISO quality assurance management processes across every stage of production. From raw material inspection and machining to assembly and final testing, each step strictly follows ISO guidelines. This ensures product consistency, traceability, and compliance with international quality standards, reinforcing our commitment to delivering reliable and globally recognized linear guide rail & carriage assemblies.

DTX-LG SGL low-profile linear guide block is your ideal solution. As a trusted linear guide manufacturer and linear guideway factory, we deliver high-quality products fully compatible with IKO linear guideways and designed as a cost-effective replacement linear guide for Hiwin systems. The SGL cnc linear guide features an extended length that increases contact area and boosts moment load capacity, making it perfect for handling heavy radial, reverse radial, and lateral loads. Its low profile design matches SGW standard block height, overcoming space limitations while maintaining the same rated load capacity—install directly without modifying your rails. With smoother travel, higher guiding accuracy, and reduced deflection under moment loads, this linear motion block for CNC machines helps achieve superior precision and stability. Ideal for CNC machining centers, automation systems, and semiconductor manufacturing, it’s the upgrade your equipment needs for consistent, high-performance motion.

Questions? You’re covered

The DTX-LG SGL long block linear guide is a high-performance low-profile linear block designed to offer superior load capacity and stability. It is fully compatible with Hiwin HGL replacement and IKO linear guideways, providing a cost-effective solution for your linear motion needs. This guide is ideal for high-precision applications such as CNC machines and automation systems.

01. What is the DTX-LG SGL long block linear guide?

DTX-LG as linear motion guide block manufacturer provide carriage guide rail solutions in flange type linear blocks with sizes 15, 20, 25, 30, 35, 45, 55, and 65. These linear blocks are designed for heavy-duty applications requiring stability and precision.

02. Can the DTX-LG SGL be used as a Hiwin HGL replacement?

Yes, the DTX-LG SGL long block is a direct CNC linear guide block replacement for Hiwin HGL systems. Its design offers the same load-bearing capacity and performance, making it easy to upgrade without changing your existing rail setup.

03. What makes DTX-LG SGL ideal for high-precision linear motion systems?

The DTX-LG SGL long block provides enhanced stability and smoother motion, reducing deflection and improving guiding accuracy. This makes it an excellent choice for high-precision linear motion systems in CNC machines and other critical applications.

04. How does the DTX-LG compare to other linear guideway carriages?

Compared to traditional linear guideway carriages, the DTX-LG offers longer blocks with greater contact area, which leads to better moment load distribution and higher overall stability. This makes it particularly well-suited for applications with heavy or eccentric loads, ensuring smooth, accurate motion in even the most demanding conditions.

05. Can DTX-LG SGL be used in automation systems?

Absolutely. The DTX-LG SGL long block is designed for use in various automation applications, providing precise linear motion and load handling. Its compatibility with linear guideway factories ensures that it meets industry standards for reliability and performance in high-speed, high-load systems.
