DTX-LG Low Profile Linear Guide
SE SERIES
Low Profile Linear Guides
Low-profile linear guides deliver precise, smooth motion within an exceptionally compact and slim design. Their reduced height and size make them ideal for space-constrained applications, enabling more efficient machinery layouts and lighter assemblies without compromising performance.Despite their small size, these guides offer excellent rigidity and load capacity relative to their profile. Optimized rail and block designs ensure stable motion with minimal deflection under light-to-moderate loads. While high-profile guides excel in heavy-duty applications requiring maximum stiffness and load capacity (e.g., CNC machines), low-profile guides provide a space-saving and cost-effective solution for moderate loads.They are widely used where space is limited but precision is critical, including semiconductor manufacturing, medical devices, 3D printers, small automation systems, and precision instruments.
Low profile linear guide Square block SEH
Havy duty linear Guide unit
Havy duty linear Guide unit
Compact Linear Guides UNIT
heavy duty linear slide rails SGR
Order Of low profile mini rail linear guide
Free Samples Available！
We’re glad to provide you with free samples. You can choose to pay for shipping either upon receipt or in advance. Just let us know what you need, and we’ll ensure your satisfaction before you make a purchase.
Why Choose DTX-LG as Your Linear Guide Manufacturer?
DTX-LG develops dustproof accessories with enhanced high dustproof function for working environments that are more stringent than general environments. If you need the following high dustproof accessories, please add the code after the product model.
The accuracy of the SG series linear guides is divided into five levels: ordinary, high, precision, ultra-precision and ultra-high precision. Customers can choose the accuracy according to the accuracy requirements of the equipment.
DTX-LG linear guides feature excellent dimensional accuracy and standardized design, ensuring high interchangeability. They can directly replace major brands like THK and HIWIN, offering a cost-effective alternative.
DTX-LG provides two types of linear guides: flange type and square type. The square type linear guide is divided into H type and L type. The L type is a low-assembly linear guide of the H type, and its combined height is the same as that of the flange type linear guide.
DTX-LG provides two types of linear guides: flange type and square type. The square type linear guide is divided into H type and L type. The L type is a low-assembly linear guide of the H type, and its combined height is the same as that of the flange type linear guide.
Certificates and Patents
DTX-LG linear guide come with a host of certifications—functional and design patents, ISO 9001, ISO 13485, ISO 45001, ISO 14001, virus & bacterial filtration tests, and more. We continually add credentials to ensure quality.
Questions? You’re covered
As a manufacturer of linear guide rails, DTX-LG offers professional service from R&D and production to final adjustment. We look forward to exploring new challenges with you.
01. What is a low-profile linear guide?
A low-profile linear guide is a slim, compact guide system designed to provide precise linear motion while occupying minimal space. It is fully compatible with HIWIN EG series, allowing direct replacement without modifying the mounting setup.
02. Can low-profile linear guides handle heavy loads?
Miniature linear guide rail are suitable for light to moderate loads. For extremely heavy loads or high-rigidity requirements, high-profile linear guides are recommended.
03. What industries use low-profile linear guides?
Commonly used in semiconductor manufacturing, medical equipment, 3D printing, small automation systems, and precision instruments.
04. How does it differ from high-profile linear guides?
Low-profile guides have a reduced height and size, making them ideal for space-constrained applications, whereas high-profile guides offer higher rigidity and load capacity for heavy-duty tasks.
05. How do I choose the right low-profile linear guide for my application?
Consider load, travel length, precision requirements, operating speed, and space constraints. Our technical team can assist with tailored recommendations.
06. What should I verify before replacing Hiwin with DTX-LG?
DTX-LG linear guides can be interchanged with Hiwin linear rails, befor order you should confirm these specifications:
Dimensional compatibility: Rail width, bolt hole spacing, block height, and mounting hole positions.
Performance specs: Load capacity, rigidity, and precision class must meet or exceed application requirements.
Block/rail interface: Ensure the slider block’s mounting holes align with existing machine structures.
Sealing & lubrication: Match sealing technology (e.g., IP ratings) and lubrication type.
